12


SELF-CENTRER MACHINE VICE

Parallism:0.01/100mm
Squareness:0.02mm

Order code
3140-
Width of jaw A
(mm)
Max opening B
(mm)
Height of jaw C
(mm)
Length of vice L
(mm)
Width of vice W
(mm)
Height of vice H
(mm)
Packing
(cm)
G.W/N.W.
(kg)
5201 100 205 37 460 100 95 51x16x15 17/16
5202 160 255 50 610 160 190 70x21x20 44/43

Order code
3140-
Width of jaw A
(inches )
Max opening B
(inches )
Height of jaw C
(inches )
Length of vice L
(inches )
Width of vice W
(inches )
Height of vice H
(inches )
5201 4" 8" 1.5" 18" 4" 3.7"
5202 6" 10" 2" 24" 6" 7.5"
