CROSS SLIDE TABLE WITH SWIVEL BASE
Parallism:0.03/100mm
Squareness: 0.05/100mm
Order code
3002- |
A
mm |
B
mm |
C
mm |
D
mm |
E
mm |
F
mm |
G
mm |
H
mm |
J
mm |
K
mm |
X Travel
mm |
Y Travel
mm |
Qty/Ctn |
Packing
cm |
NW/GW
kg |
| 6301 |
225 |
175 |
12 |
72 |
138 |
175 |
232 |
195 |
|
96 |
105 |
90 |
1 |
36x36x20 |
16/17 |
| 6302 |
330 |
220 |
12 |
72 |
155 |
280 |
160 |
240 |
200 |
96 |
190 |
100 |
1 |
41x36x19 |
28/33 |
| 6303 |
425 |
240 |
12 |
72 |
165 |
335 |
340 |
250 |
250 |
123 |
225 |
150 |
1 |
60x44x19 |
47/53 |
| 6304 |
600 |
240 |
12 |
72 |
165 |
335 |
340 |
250 |
250 |
123 |
400 |
150 |
1 |
77x44x19 |
55/60 |
Order code
3002- |
A
(inches) |
B
(inches) |
C
(inches) |
D
(inches) |
E
(inches) |
F
(inches) |
G
(inches) |
H
(inches) |
J
(inches) |
K
(inches) |
X Travel
(inches) |
Y Travel
(inches) |
| 6301 |
9" |
7" |
0.5" |
2.8" |
5.4" |
6.9" |
9" |
7.7" |
|
3.8" |
4" |
3.5" |
| 6302 |
13" |
9" |
0.5" |
2.8" |
6" |
11" |
6.3" |
9.4" |
8" |
3.8" |
7.5" |
4" |
| 6303 |
17" |
9.4" |
0.5" |
2.8" |
6.5" |
13.2" |
13.4" |
9.8" |
9.8" |
4.8" |
9" |
6" |
| 6304 |
24" |
9.4" |
0.5" |
2.8" |
6.5" |
13.2" |
13.4" |
9.8" |
9.8" |
4.8" |
16" |
6" |
|
